AX PRO with wired zones | Allarme perimetrale esterno senza fili | Kit antifurto casa professionale | Sistema di sicurezza antintrusione | Artelettric Shop

• Centrale 96 zone 16 Ingressi filari
• Videoverifica,
• Alimentatore 12Vcc/1A,
• Alloggiamento Batteria 7Ah

• TCP/IP, Wi-Fi, and 3/4G network
• New generation wireless protocol: Tri-X/Cam-X
• Long RF transmission distance
• Two-way communication with AES-128 encryption
• Connects up to 96 zones/outputs (Including 48 PIRCAMs & onboard Wired Zones/Outputs), 48 wireless keyfobs, 4 repeaters, 6 sounders(3 internal+3 External), 8 tag readers & keypads.
• Supports up to 48 network users, including 1 installer, 1 administrator, and 46 normal users
• Voice prompt
• Configuration via Web client, mobile client, and Convergence Cloud
• Hik-Connect and Hik-ProConnect configuration depends on the user access level
• Pushes alarm notification via messages or phone calls
• Views live videos from Hik-Connect
• Alarm video clips via emails and APP
• Supports LED indicator to indicates system status
• SIA-DC09 protocol, and supports both Contact ID and SIA data format
• Supports Hik-IP Receiver and Hik-IP Receiver Pro for ARC communication

Software features

• Tag    48
• Area    32
• Zones    Up to 96 (including 48 PIRCAMs & 16 onboard Wired Zones & 2 onboard Wired Outputs)
• Onboard video clips    4
• Installatore    1
• User    46
• Admin    1
• Voice Prompt    Supported
• Loudspeaker built in    Supported
• Tag reader built in    No
• Memory Log stored    5000
• Programming tools    Hik-Connect/Hik-ProConnect/Web Portal/ IVMS4200/ Convergence Cloud
• Firmware upgrade    APP/Web Portal
• Arm modes    Away/Stay
• Automatic Arm/Disarm Timers    Supported
• Forced Arming with Open Zones    Supported
• Diagnostics via the APP or Web    Supported
• ARC protocol    SIA DC09(SIA level 2, Contact ID), ISUP, ISAPI (SDK) Hik-IP Receiver & Hik-IP Receiver Pro (Sur-Gard & Ademco 685) Supports video verification and remote control
• User APP for operating    Supported
• Installer APP for programming    Supported
• Web server for maintenance (offline configuration)    Supported

Hardware features

• Power Output    2 onboard (12v, total 1A)
• RS232 output    Supported
• SIM slot    Dual

RF transmission

• Two-way Wireless Communication    Support
• RF Frequency    868Mhz
• Wireless Security    Frequency Hoping 128 AES Encryption
• 3/4G on board    Supported

Electrical characteristics

• Power supply    Built in power supply
• Battery type    12v 7Ah Storage battery (Battery is not included by default)
• Battery life span    Up to 36 hours at normal temperature (The battery working time can be significantly reduced at low temperatures)(Battery life varies from different battery types)

Wireless transmission

• Wired network    Supported
• Wi-Fi Standard    Supported

Display

• LEDs Status    Arm/Disarm, Alarm, Tamper, Fault, Cloud, Power

General

• Operation temperature    -10 °C to 40 °C
• Shell material    Plastic
• Dimension(WxHxD)    261*199*86.4mm
• Weight    1083g (No battery)
• Color    White

Device management

• Keyfob    48
• Wireless sounder    6 (3 internal+3 External)
• Keypad    8 (Including Tag reader)
• Wireless Repeater    4
• Multi Transmitter    5
• PIR Cam    Supported
